Performance & Characteristics
This machine is suitable for variety kinds of paper tubes such as textile cores; stretch film cores and other industrial paper tubes & cores.
1. This machine adopted with PLC controller; touch screen man-machine interface. Easy for parameters setting & operating.
2. Raw tube loading and finished tube unloading are totally automatic.
3. All the brands of components like Motor; Inverter; PLC; Touch Screen can be customized as per your requirement.
Technical Parameter
Inner diameter | 76-152mm |
Wall Thickness | 5-20mm |
Mother Tube Length | 3000mm |
Cutting Length | 400-3000mm |
Cutting Blade | Multi-cutters (8 pcs) |
Cutting Way | Blades; shaft and tube rotate |
Speed | 4 mother tubes/min. |
Tube Feeding / Removing | Automatically |
Speed Regulation | By Inverter |
Working Air Pressure | 0.6Mpa |
Operator | 1-2 persons |
Power Supply | 380V / 3 Phase / 50Hz |
Measurement | 7500*2050*1400mm |
Weight | 1350kgs |
