Performance & Characteristics
This machine is suitable for small & thin cores.
Technical Parameter
Inner diameter | 10-45mm |
Wall Thickness | 1-4mm |
Mother Tube Length | 650mm |
Cutting Tube Length | 40-650mm |
Cutting Blade | 6 pieces |
Cutting Way | Motor controlled |
Cutting Speed | 10 times/min. |
Operator | 1 person |
Tube Loading | Manual |
Tube Unloading | Automatic |
Working Air Pressure | 0.6Mpa |
Power Supply | 380V / 3 Phase / 50Hz |
Measurement | 1300*700*1200mm |
Weight | 480kgs |
Mandrel shaft | 2 pieces |
Tool | 1 set |
